LUBRICATION
Low Pressure Manual Filler & Pneumatic Pumps for Centralised Lubrication Systems

Description Images and specifications can be subject to change without notice Part No.
centraFILL-standard Filler Pump

Filler pump for centralised lubrication systems
with keg lid with 3 thumb screws and follower plate
PVC hose - 2,0 meters
Quick release coupling (ISO-Norm 7241B DN6/1/4")
for grease NLGI 000 - 2
centraFILL 5-s for 5 kg Kegs, Inner-Ø 165 - 200 mm 33 805 40
centraFILL 10-s for 10 kg Kegs, Inner-Ø 215 - 230 mm 33 810 42
centraFILL 15-s for 12.5 - 15 kg Kegs, Inner-Ø 255 - 282 mm 33 815 54
centraFILL 20-s for 18/20 kg Kegs, Inner-Ø 265 - 285 mm 33 818 44
centraFILL 20-s for 18/20 kg Kegs, Inner-Ø 285 - 305 mm 33 818 51
centraFILL 25-s for 25 kg Kegs, Inner-Ø 300 - 335 mm 33 825 44
centraFILL 50-s for 50 kg Kegs, Inner-Ø 355 - 387 mm 33 850 40
centraFILL-deluxe Filler Pump "JOKEY" for 18/20 kg JOKEY Plastic Pail

as described above,
including self centering cover with special claws
for maximum secure grip on the JOKEY pail (Jet 2000)

centraFILL 20-d for 18/20 kg JOKEY plastic pail 33 817 38
Pneumatic Filler Pump pneuMATO-fill, Static for 18/20 kg JOKEY Plastic Pail

as described in Pneumatic Filler Pumps Below,
including self centering cover with special claws
for maximum secure grip on the JOKEY pail (Jet 2000)
pneuMATO-fill-20-d for 18/20 kg JOKEY plastic pail 33 721 18
Pneumatic Filler Pump pneuMATO-fill, Pump

Pneumatic filler pump,
suitable for high viscosity oils, i.e. tacky chain lubricants,
for Grease NLGI 000 -2
Note: these pumps must not be used for high pressure
lubrication through grease nipples.
Technical Data :
Output at 8 bar (115 psi) air pressure: 1,800 grm/min approx.
(Multi purpose grease NLGI 2 at 20° C)
Pressure Capability 24 bar / 330 psi approx, Pump Ratio : 1:3
Thread 1/2" (M).
Pump for 10-25 kg Grease Kegs,Suction Tube 525 mm 33 725 45
Pump for 50 kg Grease Kegs, Suction Tube 790 mm 33 750 41 It is important that all
pneumatic pumps are
Pump for 200 kg Grease Kegs, Suction Tube 940 mm 33 720 26 used with an air
management system:
Pump for 1000 l Tank, Suction Tube 1490 mm 33 720 40 see page 45
Pneumatic Filler Pump pneuMATO-fill, Static

Pneumatic grease pump as described above for filling
centralised lubrication systems with QR coupler.
The kit consists of a pneumatic pump, 2 meter hose DN12 (1/2")
with quick release coupling (ISO-Norm 7241B DN6 / 1/4"),
follower plate and self centering keg lid.
Technical data see above
pneuMATO-fill-10-d for 10 kg Kegs, Inner-Ø 215-230 mm 33 710 12
pneuMATO-fill-15-d for 12.5 - 15 kg Kegs, Inner-Ø 255-282 mm 33 715 24
pneuMATO-fill-20-d for 18/20 kg Kegs, Inner-Ø 265-285 mm* 33 720 71
pneuMATO-fill-20-d for 18/20 kg Kegs, Inner-Ø 285-305 mm 33 720 57
pneuMATO-fill-25-d for 25 kg Kegs, Inner-Ø 300-335 mm 33 725 21
pneuMATO-fill-50-d for 50 kg Kegs, Inner-Ø 355-387 mm 33 750 10
pneuMATO-fill-200-d for 200 kg Kegs, Inner-Ø 550-590 mm 33 720 02
